The operating dimensions of the clamping unit and of the head-tool carriage allow to operate on the whole range of wheels, including super-single.
The controls, with lever type hydraulic distributors, enable to regulate the speed of the tool holding carriage.
STANDARD
Quick manual rotation. manual tool rotation with quick unlocking device.
Easy controls 120° rotation.
Minimum height 370 mm (14,5”).
Minimum clamping ø 90 mm (4”).
Mounting head and mounting lever, Quick-Fit system mounting tool, hydraulic operating unit, truck, bus and agriculture, rim diameter 11 -…
Mounting head and mounting lever, Quick-Fit system mounting tool, hydraulic operating unit, truck, bus and agriculture, rim diameter 11 -…
Adapters to increase clamping capacity | 1 set / 4 pieces
1 set / 4 pieces
Protection for alloy rims
For tubeless tyres
For wheel assembly machines
With increased adherence
Kit for cable or Bluetooth operation | incl. cable
1 piece
Accessory for commercial tyre changers
Short, patented
| Features | Tyre changer NAV11N 400 V – 3 Ph – 50 Hz | Tyre changer NAV11N | Tyre changer NAV11N 230 V – 1 Ph – 50 Hz |
|---|---|---|---|
| Mounting head design | With tire lever | With tire lever | With tire lever |
| Mounting arm design | Moveable | Moveable | Moveable |
| Mounting column design | Rigid | Rigid | Rigid |
| Colour | 3002RAL | 7016RAL | 3002RAL |
| TeqLink | Not possible | Not possible | Not possible |
| Workshop-Net | Not possible | Not possible | Not possible |
| Clamping device design | central | central | central |
| Min. clamping capacity | 11″ | 11″ | 11″ |
| Max. clamping capacity | 27″ | 27″ | 27″ |
| Max. rim width | 36,4″ | 36,4″ | 36″ |
| Min. rim diameter | 11″ | 11″ | 11″ |
| Max. rim diameter | 27″ | 27″ | 27″ |
| Tire type truck | Standard | Standard | Standard |
| Max. wheel width | 925mm | 925mm | 925mm |
| Max. wheel diameter | 1640mm | 1640mm | 1640mm |
| Max. wheel weight | 1500kg | 1500kg | 1500kg |
| Automatic bead-breaking movement | No | No | No |
| Bead breaker force | 18kN | 18kN | 18kN |
| Rotation speed | 8rpm | 8rpm | 8rpm |
| Max. torque | 3000Nm | 3000Nm | 3000Nm |
| Chuck motor rating | 2kW | 2kW | 2kW |
| Driving power | 0,75kW | 0,75kW | 0,75kW |
| Electrical connection | 230 – 240 V | 50 Hz | 230/400 V | 50 Hz | 230 – 240 V | 50 Hz |
| Phases | 1 | 1 | 1 |
| Fuse protection | 24A slow-blow | 24A slow-blow | 24A slow-blow |
| Width | 2810mm | 2810mm | 2810mm |
| Depth | 1620mm | 1620mm | 1620mm |
| Height | 1860mm | 1860mm | 1860mm |
| Weight | 454kg | 454kg | 454kg |
| Country of Origin, customs | IT | — | IT |
