Tyre changer NAV101 400 V - 3 Ph - 60 Hz

Tyre changer NAV101 400 V – 3 Ph – 50 Hz

Mounting head and mounting lever, for commercial vehicle tubeless tyres, synchronized double bead breaking, max. speed 8 rpm, hydraulic operating unit, truck, rim diameter 11 – 27″, max wheel width 540 mm | Red (RAL 3002)

MPN: ROT.NV101.201850
GTIN (EAN): 5063084201850
Category:
Tags: ,
Request Information

Share on:

Media

Similar Products

    Accessories

    Tech Data

    FeaturesTyre changer NAV101 400 V - 3 Ph - 50 HzTyre changer NAV101 400 V – 3 Ph – 50 Hz
    Mounting head designwith tire lever
    Mounting arm designmoveable
    Mounting column designrigid
    Colour3002RAL
    TeqLinknot possible
    Workshop-Netnot possible
    Clamping device designcentral
    Min. clamping capacity11″
    Max. clamping capacity27″
    Max. rim width52″
    Min. rim diameter11″
    Max. rim diameter27″
    Tire type truckStandard
    Max. wheel width540mm
    Max. wheel diameter1320mm
    Max. wheel weight1200kg
    Automatic bead-breaking movementNo
    Bead breaker force12,5kN
    Number of mounting speeds2
    Rotation speed8rpm
    Max. torque2600Nm
    Chuck motor rating2kW
    Driving power15kW
    Electrical connection400 V | 50 Hz
    Phases3
    Fuse protection16A slow-blow
    Width2810mm
    Depth1410mm
    Height2130mm
    Weight680kg
