Electronic digital wheel balancer Librak345WS

3D with sonar, backlit LCD graphic display (132 x 40 mm), passenger car and van, rim diameter 10 – 26″, max. wheel capacity 43″ | Red (RAL 3002)

MPN: ROT.LB345.200488
GTIN (EAN): 5063084200488
Category:
Tags: ,

Share on:

Description

Electronic automatic balancing machine con LCD display

Computerised electronic balancing machine with automatic stopping of the wheel in both internal and external unbalance position. Rapid balancing program selection with internal gauge and automatic distance and diameter acquisition.

  • Utmost precision
  • Practical design
  • Intuitive technology
  • Run-out measurement: measurement of rim eccentricity with the distance gauge
  • Eco-Weight: modern system for resetting the unbalance to reduce weight consumption
  • Program selection: rapid selection with the distance gauge
  • Wide frame for greater stability and measurement precision
  • Double LED light and laser blade (with six o’clock line for adhesive weights) for easy application of the weight in the proper position
  • Professional rapid ring nut
  • Locking in position: automatic stopping of the wheel in both internal and external unbalance position.
  • Width gauge
  • Backlit LCD 132 x 40 mm graphic display
  • Large trays for clip-on and adhesive weights
  • Automatic acquisition of the width by lowering the wheel protection
  • Hidden weight program to place the weights behind the spokes

Accessories

Delivery

Tech Data

FeaturesElectronic digital wheel balancer Librak345WSElectronic digital wheel balancer Librak345WS
Wheel data recordingfully automatic
Colour3002RAL
Tread depth measurementnot possible
TeqLinknot possible
Workshop-Netnot possible
Measuring speed< 100rpm
Measuring time6s
Balancing accuracy +/-1g
DisplayLCD, backlit
Min. rim width1,5″
Max. rim width22″
Min. rim diameter10″
Max. rim diameter26″
Max. wheel diameter1090mm
Max. wheel weight70kg
Power supply220 – 240 V | 50 – 60 Hz
Phases1
Width1260mm
Depth900mm
Height1700mm
Weight127kg
