Electronic digital wheel balancer Librak345

2D, backlit LCD graphic display (132 x 40 mm), passenger car and van, rim diameter 10 – 26″, max. wheel capacity 43″ | Red (RAL 3002)

MPN: ROT.LB345.200532
GTIN (EAN): 5063084200532
Category:
Tags: ,

Share on:

Description

Electronic automatic balancing machine con LCD display

Computerised electronic balancing machine with automatic stopping of the wheel in both internal and external unbalance position. Rapid balancing program selection with internal gauge and automatic distance and diameter acquisition.

  • Utmost precision
  • Practical design
  • Intuitive technology
  • Run-out measurement: measurement of rim eccentricity with the distance gauge
  • Eco-Weight: modern system for resetting the unbalance to reduce weight consumption
  • Program selection: rapid selection with the distance gauge
  • Wide frame for greater stability and measurement precision
  • Double LED light and laser blade (with six o’clock line for adhesive weights) for easy application of the weight in the proper position
  • Professional rapid ring nut
  • Locking in position: automatic stopping of the wheel in both internal and external unbalance position.
  • Backlit LCD 132 x 40 mm graphic display
  • Large trays for clip-on and adhesive weights
  • Hidden weight program to place the weights behind the spokes

Media

Similar Products

Accessories

Delivery

Tech Data

FeaturesElectronic digital wheel balancer Librak345Electronic digital wheel balancer Librak345Electronic digital wheel balancer Librak345WSElectronic digital wheel balancer Librak345WS
Wheel data recordingsemi-automaticfully automatic
Colour3002RAL3002RAL
Tread depth measurementnot possiblenot possible
TeqLinknot possiblenot possible
Workshop-Netnot possiblenot possible
Measuring speed< 100rpm< 100rpm
Measuring time6s6s
Balancing accuracy +/-1g1g
DisplayLCD, backlitLCD, backlit
Min. rim width1,5″1,5″
Max. rim width22″22″
Min. rim diameter10″10″
Max. rim diameter26″26″
Max. wheel diameter1090mm1090mm
Max. wheel weight70kg70kg
Electrical connection220 – 240 V | 50 – 60 Hz220 – 240 V | 50 – 60 Hz
Phases11
Width1210mm1260mm
Depth900mm900mm
Height1700mm1700mm
Weight125kg127kg
