4-post lift SM35LT-51-MB

3.5 t, electrohydraulic, incl. wheel-free jack, track length 5100 mm

MPN: SM35LT-51-MB
Category:
Tags:

Share on:

Description

The electro-hydraulic 4-post lift SM35LT-51-MB is ideal for service work, wheel assembly and dialog reception.

  • Wide, stable tracks
  • With wheel-free lift 3.5 t
  • Suitable for all passenger and utility vehicles with long wheelbase
  • The electro-hydraulic 4-post lift SM35LT-51-MB is equipped with a pneumatically lockable set-down device.
  • Wide tracks allow safe and comfortable driving onto the lift from small passenger vehicles to utility vehicles or SUVs without having to change the track width.
  • The maintenance-free lifting cylinder is positioned below the driving surface and thus protected from external influences.
  • The up, down and lowering functions on the set-down device can be conveniently controlled via operating buttons.
  • The high-performance hydraulic unit ensures a powerful stroke and short lifting and lowering periods.
  • The cold-formed driving surface profile provides high rigidity.
  • Integrated running rails allow the use of jacking beams.
  • The SM35LT-51-MB features a wheel-free lift (LT) with a stepless extension (up to 2100 mm).

Media

Similar Products

Accessories

Delivery

Tech Data

Features4-post lift SM35LT-51-MB4-post lift SM35LT-51-MB4-post lift SM65-55-MB4-post lift SM65-55-MB
Number of columns44
Mode of driveelectrohydraulicelectrohydraulic
Controlelectricelectric
Type of installationfloor mountedfloor mounted
Rated load capacity3500kg6500kg
Max. lifting height1990mm1990mm
Lifting time45s45s
Drive-on-height202mm201mm
Drive-through width2986mm2986mm
Surface coatingPowder coatedPowder coated
Wheel alignmentoptionalstandard
Length of platforms5100mm5500mm
Width of platforms650mm650mm
Space of platforms900mm900mm
Wheel free liftstandardnot possible
Rated load capacity of wheel free lift3500kg
Lifting height of wheel free lift430mm
Lifting time – Wheel free lift10s
Length of wheel free lift1490 – 2100mm
Driving power4,0kW4,0kW
Electrical connection230/400 V | 50 Hz230/400 V | 50 Hz
Air supply8bar8bar
Max. air supply10bar10bar
Length6520mm6930mm
Width3522mm3522mm
